Ducane 12W61 Counterflow Kit BCS2M24 BCS2M36 BCS2M42 BCS2M48

Product Description

The DUCANE 12W61 is a counterflow conversion kit designed for use with specific BCS2M-series air handlers. It allows the unit to discharge conditioned air downward rather than upward, changing the airflow orientation to suit installations where counterflow configuration is required. HVAC technicians install this kit when the equipment layout demands downflow air delivery, such as when the air handler is positioned above the conditioned space. The kit is an OEM-sourced accessory matched to the BCS2M-series platform.

This kit applies to residential air handler installations where the system must be configured for counterflow operation. Typical scenarios include attic or elevated mechanical room installations where supply air is directed downward into the duct system below. Compatible models are limited to those listed by the manufacturer: BCS2M24, BCS2M36, BCS2M42, and BCS2M48 air handlers.

Key Features

• Converts BCS2M-series air handlers to counterflow (downflow) air discharge orientation
• OEM accessory kit matched to four BCS2M model sizes
• Supports installations requiring downward air delivery into the supply duct system
• Direct-fit design eliminates field fabrication for airflow conversion

Compatibility

Designed for use with DUCANE BCS2M24, BCS2M36, BCS2M42, and BCS2M48 air handlers only.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the air handler before beginning any work. Follow the manufacturer's installation instructions included with the kit and verify that the duct system layout is properly configured for counterflow operation before startup.

Technical Specifications

• Application: Counterflow conversion for BCS2M-series air handlers

Standard Information

• Brand: DUCANE
• Manufacturer Part Number: 12W61
