Honeywell S87C1030 Direct Spark Ignition Module 21 Sec Trial Time

Product Description

The Honeywell S87C1030 Direct Spark Ignition Module controls ignition systems for gas-fired appliances. It operates on a twenty-four volt alternating current and is rated at zero point two amperes. This module is suitable for both liquid propane and natural gas applications. The ignition module is designed to generate high voltage potential for the main burner ignition and includes a lockout feature that activates after one ignition trial if the burner does not ignite.

• Controls ignition for gas-fired furnaces and boilers
• Includes a lockout function after one ignition attempt
• Resettable from the thermostat

Product Highlights

The Honeywell S87C1030 provides reliable ignition control, making it suitable for a range of heating applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: S87C1030

Technical Specifications

• Series: S87C
• Gas Type: Liquid Propane/Natural Gas
• Dimensions: 1-15/16 Inch L x 4-1/16 Inch W x 5-1/4 Inch H
• Reset Time: 0.8 sec
• Warm Up Time: 0.8 sec
• Amperage Rating: 0.2 A
• Control Voltage: 24 VAC
