Field Controls DI-2 Draft Inducer for 5-8 Pipe Replaces Tjernlund D-3, D3

Product Description

The Field Controls DI-2 Draft Inducer is designed to improve the drafting for chimneys, vent pipes, and negative building pressures. This draft inducer is perfect for installations in oil or gas-fired furnaces, water heaters, and boilers. It ensures efficient venting of single or multiple appliances with the use of a control kit. The DI-2 model is suitable for 5 to 8 inch pipes, replacing the Tjernlund D-3 model.

• Suitable for 5 to 8 inch pipes
• 115 volts and 60 hertz
• Replaces Tjernlund D-3, D3

Product Highlights

Field Controls DI-2 Draft Inducer efficiently improves chimney drafts for various heating applications.

Product Information

Standard Information

• Brand: Field Controls
• MPN: DI-2
• Type: Draft Inducer
• Application: Gas/Oil Heating

Technical Specifications

• Voltage: 115
• Hertz: 60
• Wattage: 78 W
• Amperage: 1.1 A
• RPM: 1550
• Inlet Diameter: 8 inches
• Outlet Diameter: 12 inches
• Pipe Diameter: 5 to 8 inches
• Maximum Heater BTU Input for Gas Appliance: 353,000 BtuH
• Maximum Heater BTU Input for Oil Appliance: 412,000 BtuH
• Housing Material: Galvanized Steel
• Country of Origin: United States
• Weight: 8.69 pounds
