ABB DP40C3P-1 Type DP Contactor, 120 VAC, 40 Amp, 3-Pole

Product Description

The ABB DP40C3P-1 Type DP Contactor is an industrial-grade contactor designed for heavy-duty applications. It has a 120 VAC coil and a current rating of 40 amps. This 3-pole contactor is suitable for controlling and protecting electric motors and other high-power loads.

• 120 VAC coil voltage
• 40 amp maximum load current
• 3-pole configuration

Product Highlights

The ABB DP40C3P-1 is engineered for high performance and reliability in industrial environments. It features a non-reversing contact type and includes auxiliary contacts for expanded functionality. It's designed for HVAC and refrigeration equipment operation and control.

Product Information

Standard Information

• Brand: ABB
• MPN: DP40C3P-1

Technical Specifications

• Coil Voltage: 120 VAC
• Contact Type: Non-Reversing
• Mounting Type: DIN Rail
• Terminal Type: Box Lug
• Contact Rating: 600 VAC
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Coil Power Rating: 6/7.5/60/65 VA
• Maximum Load Current: 40 A
• Contact Configuration: 3NO
• Operating Temperature: 130 deg C
• Number of Auxiliary Contacts: 1NO-1NC
• Dimensions: 3.39 in H x 2.41 in W x 2.98 in D
