Metal-Fab 5M24 Twist-Lock Type B Double Wall Gas Vent Pipe 5 Inch x 24 Inch

Product Description

The Metal-Fab 5M24 is a double wall Type B gas vent pipe specifically designed for approved category I appliances. This vent pipe has a diameter of five inches and measures twenty-four inches in length. It features a twist-lock end type that ensures secure connections during installation. Constructed from durable materials, the pipe consists of a 0.012 inch thick aluminum alloy inner wall and a 0.018 inch thick galvanized steel outer casing.

• Diameter: 5 inches
• Length: 24 inches
• Temperature rating: 530 degrees Fahrenheit

Product Highlights

This vent pipe is ideal for gas boilers, fireplaces, furnaces, unit heaters, and radiant tube heaters. It meets applicable standards such as UL 441 and NFPA 54/211, ensuring safety and reliability for your gas venting needs.

Product Information

Standard Information

• Brand: Metal-Fab
• Model: 5M24

Technical Specifications

• Type: Double Wall, Round, Type B Gas Vent
• Material: Aluminum Alloy (Flue), G90 Galvanized Steel (Casing)
• Material Thickness: 0.012 Inch (Inner Wall), 0.018 Inch (Outer Wall)
• Temperature Rating: 530 Degrees Fahrenheit
• Applicable Standards: UL 441, NFPA 54/211
• Clearance Required: 1 Inch
• Weight: 2.83 lbs
• UPC: 622417101981
