Dotco 12L2500-01RT Inline Air Router 0.9 Hp 23000 Rpm

Product Description

The DOTCO 12L2500-01RT is an inline pneumatic router designed for precision material removal, trimming, and routing tasks in industrial and trade environments. Rated at 0.9 HP with a no-load speed of 23,000 RPM, it accepts a 1/4 inch collet and operates at 90 psi air pressure through a 1/4 inch air inlet. Front exhaust directs airflow away from the work surface, helping maintain visibility and reduce debris blowback. The tool ships with a 1/4 inch collet and wrench included. Licensed machinists, aerospace technicians, fabricators, and finish carpenters install and operate this class of tool in production and field settings.

The 12L2500-01RT suits inline routing applications where a compact, straight-body tool profile is required. Its 7.1 inch overall length fits comfortably in standard tool rigs and jigs. Typical use cases include laminate trimming, composite routing, port work, and deburring operations where high spindle speed and consistent air supply are maintained. A 0.31 inch (7.9 mm) hose size is recommended to support proper airflow at rated pressure.

Key Features

• 23,000 RPM no-load speed suited for high-speed routing and trimming
• 0.9 HP output for consistent material removal under load
• 1/4 inch collet and wrench included — ready to use out of the box
• Front exhaust location directs air away from operator and workpiece
• 1/4 inch air inlet compatible with standard shop pneumatic lines
• Compact inline body at 7.1 inch overall length for jig and fixture use

Compatibility

Designed as an OEM-style inline pneumatic router accepting standard 1/4 inch shank tooling. Confirm collet size and air supply specifications match your existing pneumatic system before installation.

Installation Notes

Installation and operation should be performed by qualified personnel familiar with pneumatic tool systems. Shut off and bleed the air supply before connecting or disconnecting the tool from the airline. Verify the supply pressure is regulated to 90 psi and that the hose and fittings are rated for the operating pressure. Inspect the collet and tooling for wear before each use, and never exceed the rated RPM with installed tooling.
