Dormont cssd54-48 Stainless Steel Gas Connector 3/8 in

Product Description

The DORMONT cssd54-48 is a stainless steel gas connector designed for use in residential and light commercial gas appliance installations. It features a 3/8 inch nominal size with female iron pipe (FIP) end fittings on both ends, providing a secure, leak-resistant threaded connection. Rated for a working pressure of 0.5 psi and a temperature range of -40 to 150 degrees F, this connector is built to handle standard natural gas and LP gas service conditions. Licensed plumbers and gas fitters are the primary installers for this type of flexible connector.

This gas connector is suited for connecting gas-fired appliances such as ranges, dryers, water heaters, and furnaces to the gas supply line in residential and light commercial settings. The stainless steel construction resists corrosion and provides long service life in both indoor and exposed utility installations. Domestically manufactured, it meets the dimensional and material standards expected for FIP-end gas connectors in these applications.

Key Features

• 3/8 inch nominal size with FIP end style for threaded connection
• 0.5 psi working pressure rating suitable for standard gas appliance service
• Operating temperature range of -40 to 150 degrees F
• Stainless steel construction for corrosion resistance and durability
• 1/2 inch inside diameter and 1/2 inch outside diameter
• Domestically manufactured

Compatibility

Designed as an OEM-style replacement or new-installation flexible gas connector for residential and light commercial gas appliance hookups requiring a 3/8 inch nominal FIP end connection.

Installation Notes

Installation should be performed by a licensed plumber or qualified gas fitter in accordance with local codes and the International Fuel Gas Code (IFGC). Shut off the gas supply and verify zero pressure at the connection point before beginning work. Apply an approved pipe thread sealant or tape rated for gas service to all threaded joints. Inspect all connections for leaks with an approved leak detection solution before restoring gas service.

Technical Specifications

• Nominal Size: 3/8 inches
• End Style: FIP
• Inside Diameter: 1/2 inches
• Outside Diameter: 1/2 inches
• Working Pressure: 0.5 psi
• Temperature Rating: -40 to 150 degrees F
• Material: Stainless Steel
• Country of Origin: Domestic

Standard Information

• Brand: DORMONT
• Manufacturer Part Number: cssd54-48
