DORMONT 30-3131-18 Gas Connector - 1/2 in. x 18 in. Stainless Steel

Product Description

The DORMONT 30-3131-18 is an 18-inch gas connector made from 304 stainless steel. This connector includes 1/2-inch male threaded IPS ends on both sides. It is suitable for various applications in residential and commercial settings, whether indoor or outdoor, connecting ranges and furnaces.

• Constructed from stainless steel for corrosion resistance.
• 1/2 inch male threaded end connections for ease of installation.
• CSA certified for safety in indoor and outdoor use.

Product Highlights

This connector supports a minimum gas flow capacity of 164,200 BTU/HR for natural gas and 262,720 BTU/HR for propane gas, allowing for efficient operation.

Product Information

Standard Information

• Model: 30-3131-18
• Application: Residential, Commercial, Indoor, Outdoor

Technical Specifications

• Length: 18 inches
• UPC: 662447003992
• Weight: 0.73 lb
• Body Material: Stainless Steel
• End Connection 1 Size: 1/2 inch
• End Connection 2 Size: 1/2 inch
• Inner Diameter: 1/2 inch
• Outer Diameter: 5/8 inch
• Temperature Rating: -40 to 150 degrees Fahrenheit
• Minimum Flow Capacity: 164,200 BTU/HR (Natural Gas)
• Maximum Pressure: 0.5 PSI
