Dormer PREDO-18026 A120 Type N Short Length Drill Bit, 7/16 in Drill - Fraction

Product Description

The Dormer PREDO-18026 is a short length drill bit suitable for various drilling tasks. This Type N drill bit features a seven sixteenth inch diameter, making it ideal for general drilling applications in different materials.

• Type N design for effective drilling.
• Compatible with metals like aluminum and stainless steel.
• Features a right hand cutting direction for ease of use.

Product Highlights

The Dormer PREDO-18026 drill bit is designed for precision and durability. It includes a high-speed steel cutting edge and a steam oxide finish which enhances performance and longevity.

Product Information

Standard Information

• Brand: Dormer
• MPN: PREDO-18026

Technical Specifications

• Drill Diameter - Fraction: 7/16 in
• Drill Diameter - Decimal Inch: 0.4375 in
• Cutting Depth: 2.5XD
• Overall Length: 95 mm
• Shank Size: 7/16 in
• Flute Length: 47 mm
• Number of Flutes: 2
• Point Angle: 135 deg
• Flute Type: Spiral
• Point Type: Split
• Cutting Direction: Right Hand
• Cutting Edge Material: HSS
• Applicable Materials: Aluminum, Cast Iron, Copper, Hard Material, Magnesium, Nickel, Stainless Steel, Steel, Synthetic Material, Titanium
