Dormakaba Multi-housing 79PS016T1EL32626 Mortise Lockset

Product Description

The DORMAKABA MULTI-HOUSING 79PS016T1EL32626 is an RT Plus standalone RFID proximity mortise lockset with integrated deadbolt, designed for multi-housing access control applications. This unit combines electronic credential reading with a long lever handle and toggle-style thumbturn, operating over RFID proximity and Bluetooth Low Energy (BLE) communication. The Electronic Lock Override (ELO) function allows authorized override of the electronic locking mechanism without credential loss. It is field-reversible for left-hand or right-hand reverse installation and ships in a 626 Satin Chrome finish. Installation is performed by a licensed locksmith or commercial door hardware technician.

This lockset is suited for residential multi-housing and light commercial interior door applications where privacy security and electronic access control are required in a single mortise package. The 1-1/4 inch ASM (Asymmetric) faceplate accommodates standard mortise prep dimensions. The BLE capability supports mobile credential management, making it appropriate for property managers and access control integrators who require keycard and smartphone-based entry at individual unit doors.

Key Features

• Standalone RFID proximity reader with Bluetooth Low Energy (BLE) for mobile credential support
• Integrated deadbolt provides privacy and secondary locking in a single mortise body
• Electronic Lock Override (ELO) allows authorized bypass of electronic function
• Long lever handle with toggle thumbturn for ADA-style ergonomic operation
• Field-reversible handing — installs left hand or right hand reverse without additional hardware
• 626 Satin Chrome finish for durability and consistent appearance across multi-housing applications

Compatibility

Designed as an OEM-style replacement or new-installation mortise lockset for standard mortise door prep with a 1-1/4 inch ASM faceplate, suitable for multi-housing residential and light commercial door applications.

Installation Notes

Installation should be performed by a licensed locksmith or qualified door hardware technician familiar with mortise lock chassis and electronic access control wiring. Power down or disconnect any existing electronic hardware before beginning removal of a prior lockset. Verify door prep dimensions and backset against the mortise body before installation. Credential programming and BLE pairing should be completed per the manufacturer access control setup procedure before the door is returned to service.
