Donaldson P565061 Spin-On Fuel Filter

Product Description

The Donaldson P565061 is a Spin-On Fuel Filter designed for use in various fuel systems. This filter helps remove contaminants, ensuring optimal engine performance. The product features a 3.66 inches outer diameter and a 1-12 UN thread size, making it suitable for a wide range of applications.

• Outer Diameter: 3.66 inches
• Thread Size: 1-12 UN
• Media Type: Cellulose

Product Highlights

This Spin-On Fuel Filter is ideal for protecting fuel systems from debris and contaminants.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: 100181783

Technical Specifications

• Outer Diameter: 3.66 inches (93 mm)
• Length: 5.35 inches (135.8 mm)
• Thread Size: 1-12 UN
• Gasket ID: 2.42 inches (61.5 mm)
• Gasket OD: 2.81 inches (71.5 mm)
• Efficiency Beta: 24 Micron @ Beta 1000, 5 Micron @ Beta 2
• Media Type: Cellulose
• Weight: 1.15 LB
