Donaldson P550276 Spin-On Fuel Filter

Product Description

The Donaldson P550276 is a spin-on fuel filter designed for general system protection. It is essential for maintaining clean fuel supply, especially during surge flows. This filter helps ensure the smooth operation of equipment by removing contaminants from the fuel.

• Outer diameter of five point zero four inches
• Thread size of one and a half - sixteen UN
• Spin-on style for easy installation

Product Highlights

This spin-on fuel filter features a filter series compatible with W023, SP50/60, SP80/90, and SP100/120 models.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: P550276

Technical Specifications

• Outer Diameter: 5.04 inches (128 mm)
• Length: 10.66 inches (270.8 mm)
• Media Type: Wire Mesh
• Efficiency Beta: 10 Micron @ Beta 2
• Thread Size: 1 1/2-16 UN
• Weight: 3.4 LB
• Primary Application: ZINGA LE100
• Gasket I.D.: 4.76 inches (120.9 mm)
• Gasket O.D.: 5.04 inches (128 mm)
