Dodge TXT305AT Torque-Arm Shaft Mount Reducer

Product Description

The Dodge TXT305AT is a Torque-Arm shaft mount reducer known for its quality and reliability. This reducer features a tapered bushing for easy installation and maintenance. It is designed for various applications, making it suitable for both industrial and commercial use.

• Output bushing bore range from one point three one two five inches to two point one eight seven five inches
• Max input horsepower at one hundred RPM is eleven point seven HP
• Box dimensions are nine point two five inches in length, five point six two five inches in width, and twelve point eight seven five inches in height

Product Highlights

This product provides a robust solution for torque transmission while ensuring efficient space usage. It is built for durability and can handle substantial loads.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 100818224

Technical Specifications

• Output Bushing Bore Range [Min]: 1.3125 inches
• Output Bushing Bore Range [Max]: 2.1875 inches
• Input Shaft: 1 5/8 inches
• Box Length: 9.25 inches
• Box Height: 12.875 inches
• Box Width: 5.625 inches
• Drive Type: Torque Arm
• Max. Input HP @ 100 RPM: 11.7 HP
• Weight: 91.43 LB
• AGMA Unit Size: 203
• Mfr. Unit Size: TXT3
• Installed Options: N/A
• EAN or UPC: 782475679720
