Dodge S1UK204R S-1 Cartridge Unit Heavy-Duty 2 1/4 ID x 4 7/8 OD x 3 3/8 Wide

Product Description

The Dodge S-1 Cartridge Unit, part number S1UK204R, features a heavy-duty design with a size of two and one-quarter inches internal diameter and four and seven-eighths inches outer diameter. This unit is constructed from cast iron and includes labyrinth seals for effective performance. The product allows for relubrication and can be easily mounted in various configurations. The S-1 Cartridge Unit is ideal for applications requiring fixed or expansion bearing designs.

• Type K Cartridge
• Relubricatable
• Setscrew locking mechanism

Product Highlights

This cartridge unit is built for reliability in demanding environments and is suitable for lineal shaft expansion, ensuring proper alignment and function.

Product Information

Standard Information

• Brand: Dodge
• Part Number: S1UK204R

Technical Specifications

• Duty: Heavy-Duty
• Locking Device: Setscrew Locking
• Housing Material: Cast Iron
• Overall Width: 3 3/8 in
• Outside Diameter: 4.875 in
• Relubricatable: Yes
• Shaft Diameter: 2.250 in
• Housing Width: 2 3/4 in
• Bearing Design: Fixed or Expansion
• Lubrication: Relubricatable
• Type: S-1 Unit
• Bearing Type: Tapered Roller Bearing
• Seal Type: Labyrinth Seals
• Weight: 10.83 LB
• EAN or UPC: 782475697267
