Dodge P728M30SK | High Torque Drive Sprocket | 8 mm | 30 mm | 72 Teeth

Product Description

The Dodge P728M30SK is a high torque drive sprocket designed to meet the demands of various applications including agitators and conveyors. This sprocket features a belt pitch of eight millimeters and an outside diameter of seven point one sixty-four inches. It is suitable for use with QD bushings, providing ease of installation and reliability in performance.

• Designed for high torque applications
• Compact and low maintenance
• Corrosion and abrasion resistant

Product Highlights

The Dodge P728M30SK sprocket is ideal for use in mixers, blowers, and laundry machinery due to its quiet operation and positive drive. It does not require lubrication, promoting a clean and simple solution for drive systems.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 100946276

Technical Specifications

• Sprocket Width: 1.5 inches
• Belt Width: 30 mm
• Outside Diameter: 7.164 inches
• Bushing Type: QD
• Bore Range [Min]: 0.5 inches
• Bore Range [Max]: 2.625 inches
• Number of Teeth: 72
• Belt Pitch: 8 mm
• Weight: 11.28 lb
• EAN or UPC: 782475264834
