Dodge P4814M402517 High Torque Drive Sprocket

Product Description

The Dodge P4814M402517 is a high torque drive sprocket designed for various industrial applications. This sprocket features a belt pitch of fourteen millimeters and a width of forty millimeters. It has a total of forty-eight teeth and an outside diameter measurement of eight point three eleven inches. The P4814M402517 requires a bushing series of 2517 with a bore range of fifteen sixteenths inches to three inches.

• Applications include mixers and conveyors.
• Requires minimal maintenance.
• Offers quiet operation and no lubrication.

Product Highlights

The high torque drive sprocket provides a positive drive with no slip and is resistant to corrosion and abrasion. This leads to a longer operational life. Its compact design ensures it fits in limited space areas.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 101969895

Technical Specifications

• Belt Pitch: 14 mm
• Belt Width: 40 mm
• No. of Teeth: 48
• Outside Diameter: 8.311 in
• Bore Range [Max]: 3 in
• Bore Range [Min]: 0.9375 in
• Bushing Series: 2517
• Pitch Diameter: 8421 in
• Bushing Type: Taperlock
• Weight: 22.17 LB
• EAN or UPC: 782475676361
