Dodge P3414M552517 High Torque Drive Sprocket

Product Description

The Dodge P3414M552517 is a high torque drive sprocket designed for various industrial applications. This sprocket features a pitch of 14 millimeters and a width of 55 millimeters, with 34 teeth for effective power transfer.

• Applications include agitators, mixers, and conveyors
• Requires a bushing series of 2517
• Compatible with bore ranges of fifteen-sixteenths of an inch to three inches

Product Highlights

This drive sprocket operates quietly and requires low maintenance. It is compact and designed to prevent slippage, eliminating the need for lubrication.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 100946427
• Availability: Ready to Ship

Technical Specifications

• Bushing Series: 2517
• Bore Type: Taper-Lock and QD Bushed
• Belt Pitch: 14 mm
• Belt Width: 55 mm
• No. of Teeth: 34
• Outside Diameter: 5.855 in
• Pitch Diameter: 5.965 in
• Bore Range [Min]: 0.9375 in
• Bore Range [Max]: 3 in
• Weight: 11.11 LB
• EAN or UPC: 782475676286
