Dodge P2BLM8108 Stamped Steel Housing Journal Bearing 2 Bolts Pillow Block

Product Description

The Dodge P2BLM8108 is a stamped steel housing journal bearing designed for industrial applications. This product features a two-bolt pillow block configuration, providing stability and support in various settings.

• Self-lubricating and statically self-aligning.
• Temperature resistance from negative two hundred degrees Fahrenheit to one thousand degrees Fahrenheit.
• Ideal for both high heat and cold temperature applications.

Product Highlights

This bearing is suitable for areas with limited access and is submersible in certain conditions.

Product Information

Standard Information

• Brand: Dodge
• MPN: P2BLM8108

Technical Specifications

• Mounted Unit Duty: Light-Duty
• Expansion Capability: Float
• Base Height: 5/32 inches
• Locking Device: No Locking Device
• Housing Construction: Solid
• Base Length: 4.5 inches
• Shaft Diameter: 1.5 inches
• Number of Bolt Holes: 2
• Lubrication: Self-Lubricated
• Insert Material: Graphite
• Bolt Hole Length: 9/16 inches
• Length Through Bore: 1.125 inches
• Pillow Block Type: Thru-Bolt
• Greasable: No
• Seal Type: Unsealed
• Housing Material: Stamped Steel
• Housing Height: 2.0625 inches
• Bearing Type: Journal
• End Type: Open End
• Base to Center Height: 1.875 inches
• Base Width: 1.40625 inches
• Bearing Design: Non-Expansion
• Bolt Hole Spacing: 3.5 inches
• Weight: 0.51 lbs
• EAN or UPC: 782475016976
