Dodge INS-SC-115 SC Series Normal-Duty Corrosion-Resistant Bearing Insert

Product Description

The Dodge INS-SC-115 is a SC Series normal-duty corrosion-resistant bearing insert designed for various applications. This insert features a bore diameter of one and fifteen-sixteenth inches. It provides a robust solution for air handling, unit handling, and other demanding environments.

• Double-sealed to prevent contamination
• DualGuard sealing system for enhanced protection
• Setscrew locking collar for secure attachment

Product Highlights

This bearing insert is ideal for sectors such as food and beverage, automotive, and chemical processing. It combines precision engineering with reliable sealing to extend service life.

Product Information

Standard Information

• Brand: Dodge
• MPN: INS-SC-115

Technical Specifications

• Bore Type: Round Bore
• Length Through Bore: 1.75 inches
• I.D.: 1 15/16 inches
• Overall Width: 1 3/4 inches
• O.D.: 90 mm
• Outer Ring Width: 22 mm
• Weight: 1.53 lb
• Material: Steel
• Enclosure: Double Sealed
• Lubrication: Relubricatable
