Dodge FCSCM100 Flange-Mount Ball Bearing Unit 1 in Bore 4-Bolt Piloted Flange Mount

Product Description

The Dodge FCSCM100 is a flange-mount ball bearing unit designed for various industrial applications. It features a one-inch bore and is equipped with a four-bolt piloted flange mount for secure installation. The unit is made from cast iron housing material, ensuring durability and longevity. It operates effectively in medium-duty applications and has a single lip contact seal to protect against contaminants.

• Bore Diameter: 1 inch
• Radial Load Capacity: 4368 lbf
• Maximum Speed: 4500 rpm

Product Highlights

This ball bearing unit is ideal for applications requiring reliable and efficient performance. Its fixed non-expansion design makes it suitable for diverse installation environments.

Product Information

Standard Information

• Manufacturer: Dodge
• Catalog Number: 126167

Technical Specifications

• Bore Type: Straight
• Duty Type: Medium Duty
• Seal Type: Single Lip Contact Seal
• Bore Length: 1.52 inches
• Grease Type: Unirex N2
• Lubrication: Grease
• Sensor Ready: Adapter Required
• Insert Material: Steel
• Type Of Bearing: Ball
• Housing Material: Cast Iron
• Shaft Attachment: Setscrew
• Radial Static Load Capacity: 2538 lbf
• Radial Dynamic Load Capacity: 4368 lbf
• Expansion Type: Non-Expansion Bearing (Fixed)
• Locking Device: Set Screw
• Relubricatable: Yes
