Dodge F4B-GT-203 Cast Iron Greasable 4-Bolt Flange Unit

Product Description

The Dodge F4B-GT-203 is a cast iron greasable 4-bolt flange unit designed for various applications in mechanical systems. It features a shaft diameter of two point one eight eight inches, which allows for secure mounting and effective load handling.

• 4-bolt flange for secure installation
• Greasable design for easy maintenance
• Solid cast iron housing for durability

Product Highlights

This bearing unit is suitable for both industrial and commercial uses, providing strength and reliability.

Product Information

Standard Information

• Brand: Dodge
• MPN: F4B-GT-203

Technical Specifications

• Shaft Diameter: 2.188 in
• Bore Length: 2.25 in
• Bolt to Bolt [Max]: 5.13 in
• Housing Material: Cast Iron
• Insert Material: Steel
• Lubrication: Grease
• Greasable: Yes
• Locking Device: Push-Pull Adapter
• Bearing Type: Ball
• Weight: 8.44 LB
• Expansion Capability: Fixed
• Sensor Ready: Adapter Required
