Dodge F2B-SCM-200-HT Ball Bearing Unit 2 in Bore 2-Bolt Flange Mount 064344

Product Description

The Dodge F2B-SCM-200-HT is a flange-mount ball bearing unit with a two-inch bore and a two-bolt flange mount. This unit is designed for medium-duty applications and features a set screw locking method. It has a cast iron housing material that provides durability and reliability. The labyrinth seal keeps out contaminants, ensuring a longer service life.

• Two-inch bore size
• Cast iron housing for strength
• Labyrinth seal for protection against contaminants

Product Highlights

This bearing unit is suitable for high-temperature applications and is designed to operate under fixed conditions.

Product Information

Standard Information

• Manufacturer: Dodge
• Part Number: F2B-SCM-200-HT

Technical Specifications

• Bore Diameter: 2 in
• Bore Length: 2.22 in
• Weight: 7.51 lbs
• Length: 8.3 inches
• Width: 9.35 inches
• Height: 2.75 inches
• Duty Type: Medium Duty
• Locking Device: Set Screw
• Lubrication: Grease
• Seal Type: Labyrinth
• Housing Material: Cast Iron
• Country of Origin: United States
