Dodge 50BTL36-2012SPKT Bushing Bore Roller Chain Sprocket - Taper Locking, 50 / 5/8 in, 36 Teeth, 2012 Bushing

Product Description

The Dodge 50BTL36-2012SPKT is a bushing bore roller chain sprocket designed for mechanical power transmission. This sprocket features a taper locking design which ensures secure fitment on a variety of chains. With thirty-six teeth and a compatible bushing size of 2012, it is suitable for numerous applications requiring efficient power transfer.

• Steel material construction
• Compatible with 50 / 5/8 inch chain
• Hub diameter of 3.56 inches

Product Highlights

The Dodge bushing bore roller chain sprocket offers durable performance and reliability for various industrial uses.

Product Information

Standard Information

• Brand: Dodge
• Manufacturers Catalog No: 00250

Technical Specifications

• Weight: 4.10 lbs
• Material: Steel
• Pitch Type: Single
• Tooth Width: 0.343 in
• Bushing Size: 2012
• Bushing Type: Taper Lock Bushing
• Hub Diameter: 3.56 in
• Overall Width: 1-1/4 in
• Pitch Diameter: 7.17 in
• Number of Teeth: 36
• Outside Diameter: 7.5190 in
• Bushing Bore Range: 1/2 to 2-1/8 in
• Length Through Bore: 1.2500 in
• Chain Number & Pitch: 50 / 5/8 in
• Number of Hubs: 1
• Manufacturer Catalog Number: 100549
