Dodge 4B8.6-2517 SHEAVE - 4 Groove, 8.58 (A) in Pitch Diameter, Taper Lock Bushed

Product Description

The Dodge 4B8.6-2517 SHEAVE is a reliable V-belt pulley designed for mechanical power transmission applications. This particular model is part of the 2517 series and features four grooves. It measures 8.58 inches in the A belt section pitch diameter and 8.95 inches in outside diameter. Built from cast iron, it ensures durability and efficiency in various conditions.

• Isolates shock loads and vibration
• Minimal maintenance required
• Quiet operation with typical efficiency of 95%

Product Highlights

This sheave allows for easy installation with tapered lock bushings and accommodates multiple bore sizes ranging from half inch to two and eleven-sixteenths inches.

Product Information

Standard Information

• Brand: Dodge
• Country Of Origin: United States

Technical Specifications

• Weight: 26.44 lbs
• Material: Cast Iron
• Bore Type: Taper Lock Bushed
• Face Width: 3.2500 in
• Outside Diameter: 8.9500 in
• Pitch Diameter: 8.58 (A) in, 8.96 (B) in
• Number Of Grooves: 4
• Bushing Series: 2517
• Bushing Bore Range: 1/2 to 2-11/16 in
• Length Through Bore: 1.7500 in
• Pulley Construction: Plain
