Dodge 2C100-SFSHEAVE 455795 Bushing Bore V-Belt Pulley - C Belt Section, 2 Groove, 10.4 in Pitch Dia.

Product Description

The Dodge 2C100-SFSHEAVE is a bushing bore V-belt pulley designed for mechanical power transmission. It features a C belt section with two grooves, suitable for various industrial applications. The pulley has a pitch diameter of ten point four inches and an outside diameter of ten point four inches, making it a robust choice for efficient power transfer.

• Cast iron construction for durability
• QD bush design for easy installation
• Compatible with SF series bushings

Product Highlights

This V-belt pulley is ideal for use in various machinery, providing reliable performance and efficient energy transmission.

Product Information

Standard Information

• Brand: Dodge
• Country of Origin: Canada

Technical Specifications

• MPN: 2C100-SFSHEAVE
• Weight: 22.50 lbs
• Face Width: 2.3750 in
• Overall Width: 2.37 in
• Pitch Diameter: 10.4 in
• Outside Diameter: 10.4000 in
• Number of Grooves: 2
• Bushing Bore Range: 1/2 to 2-15/16 in
• Length Through Bore: 2.0000 in
