Dodge 2B3.4-1210 SHEAVE - V-Belt Pulley - 2 Groove - 1210 Series Bushing

Product Description

The Dodge 2B3.4-1210 SHEAVE is a V-Belt pulley that features a bushing bore design. This product is suitable for various mechanical power transmission applications. It is equipped with two grooves and a pitch diameter of three point three eight inches for section A and three point seven six inches for section B. The outside diameter measures three point seven five inches, ensuring compatibility with different belt sizes.

• Isolates shock loads and vibrations
• Ability to handle misalignments
• Low maintenance and no lubrication required

Product Highlights

This sheave achieves an efficiency of ninety-five percent, making it a reliable choice for V-drive systems.

Product Information

Standard Information

• Brand: Dodge
• Country Of Origin: United States

Technical Specifications

• Overall Width: one and three-fourth inches
• Face Width: one point seven five inches
• Number Of Grooves: 2
• Pitch Diameter: three point three eight (A) inches, three point seven six (B) inches
• Outside Diameter: three point seven five inches
• Bushing Bore Range: one half to one and one-fourth inches
• Length Through Bore: one inch
• Bushing Series: 1210
