Dodge 2-5V11.3-3020 SHEAVE - 5V Belt Section 11.2 in Pitch Dia. 3020 Series Bushing

Product Description

The Dodge 2-5V11.3-3020 SHEAVE is designed for V-belt applications, providing reliable performance in mechanical power transmission systems. This V-belt pulley features a two-groove design that is compatible with the 5V belt section. Its pitch diameter measures eleven point two inches, and the outside diameter is eleven point three inches. Made from cast iron, it offers durability for various industrial environments.

• Two-inch face width for effective belt engagement.
• Compatible with taper lock bushings for easy installation.
• Wide bushing bore range from seven-eighths to three and one-quarter inches.

Product Highlights

This sheave provides consistent performance for power transmission applications.

Product Information

Standard Information

• Brand: Dodge
• Country of Origin: United States

Technical Specifications

• Weight: 30.11 lbs
• Material: Cast Iron
• Bore Type: Taper Lock Bushed
• Face Width: 1.6875 in
• Keyway Size: 1/2 x 1/4, 1/4 x 1/8, 3/16 x 3/32, 3/4 x 3/8, 3/8 x 3/16, 5/16 x 5/32, 5/8 x 5/16 in
• Overall Width: 1.99 in
• Bushing Series: 3020
• Pitch Diameter: 11.2 in
• Outside Diameter: 11.3000 in
• Belt Section Size: 5V
• Number of Grooves: 2
• Bushing Bore Range: 7/8 to 3-1/4 in
• Length Through Bore: 2.0000 in
• Pulley Construction: Webbed
