Dodge 1B8.6-2517 SHEAVE - V-Belt Pulley - A, B Belt Section - 2517 Series Bushing

Product Description

Dodge 1B8.6-2517 SHEAVE is a V-belt pulley designed for effective power transmission. This pulley is made of cast iron and features a taper lock bushing. It is compatible with A and B belt sections and has one groove. It offers a wide pitch diameter and outside diameter for enhanced performance.

• Isolates shock loads and vibration
• Low maintenance with no lubrication required
• Efficiency of 95% typical

Product Highlights

Dodge 1B8.6-2517 SHEAVE effectively transmits power while providing shock isolation. Ideal for use in mechanical power transmission applications.

Product Information

Standard Information

• Brand: Dodge
• Country of Origin: United States

Technical Specifications

• Weight: 12.34 lbs
• Face Width: 1.0500 in
• Overall Width: 1.8 in
• Bushing Series: 2517
• Pitch Diameter: 8.58 (A) in, 8.96 (B) in
• Outside Diameter: 8.9500 in
• Number of Grooves: 1
• Bushing Bore Range: 1/2 to 2-11/16 in
• Length Through Bore: 1.7500 in
