Dodge 1210X30MM8X3.3MM Taper Lock Bushing

Product Description

The Dodge Taper Lock Bushing with MPN 1210X30MM8X3.3MM is essential for reliable shaft connections in various mechanical applications. Its compact design ensures easy installation and removal, making it an efficient choice for professional use.

• Compatible with metric bore sizes.
• Constructed from sintered steel.
• Offers a torque capacity of 300 lbf.

Product Highlights

This bushing simplifies the installation process with its user-friendly design.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 100791737
• Current Price: 26.31
• Availability: Ready To Ship, typically ships within 24 hours

Technical Specifications

• Wrench Torque: 14.58 lbf
• Bushing Series: 1210
• Large Diameter: 1.87 inches
• Material: Sintered Steel
• Bore Size: 30 mm
• Bolt Circle Diameter: 1 3/4 inches
• Cap Screws: 2
• Length Through Bore: 1 inch
• Keyway Size: 8 mm x 3.3 mm
• Capscrew Size: 3/8 x 5/8
• Bore Type: Metric
• Torque Capacity: 300 lbf
• Weight: 0.35 LB
• EAN or UPC: 782475538331
