Dodge 1210X16MM5X2.3MM Taper Lock Bushing

Product Description

The Dodge 1210X16MM5X2.3MM is a taper lock bushing designed for easy installation and removal. It features a bore size of sixteen millimeters and is constructed from sintered steel for durability.

• Easy on, easy off
• Flush mounting to eliminate protrusions
• Compact design for efficient space usage

Product Highlights

This bushing is ideal for mechanical assemblies needing reliable and quick coupling solutions.

Product Information

Standard Information

• Category: Finished Bore Taper Lock Bushings
• Brand: Dodge

Technical Specifications

• Bore Size: 16 mm
• Material: Sintered Steel
• Bolt Circle Diameter: 1.75 in
• Bushing Series: 1210
• Capscrew Size: 3/8 x 5/8
• Wrench Torque: 14.58 lbf
• Large Diameter: 1.87 in
• Keyway Size: 5 mm x 2.3 mm
• Length Through Bore: 1 in
• Torque Capacity: 300 lbf
• Bore Type: Metric
• Cap Screws: 2
• Weight: 0.54 lb
• EAN or UPC: 782475884032
