Dodge 006657 DOD 1090T HUB X 2-1/4

Product Description

The Dodge 006657 is a 1090T hub designed for use in grid couplings. This hub features a bore diameter of two and a quarter inches and a bore length of three point nine inches, designed to fit closely between shafts. It is suitable for applications requiring reliable performance in various environments.

• Bore Diameter: 2.25 inches
• Bore Length: 3.90 inches
• Rated Torque: 33,000 inch-pounds

Product Highlights

This coupling hub is built for durability and strength. It supports high torque applications while maintaining precise alignment.

Product Information

Standard Information

• Manufacturer: Dodge
• Part Number: 006657 DOD

Technical Specifications

• Coupling Size: 1090
• Axial Misalignment: 0.375 inches
• Angular Misalignment: 0.5 degrees
• Parallel Misalignment: 0.012 inches
• Horsepower per 100 Rat: 52.36 horsepower
• Lubrication: Grease
• Maximum Temperature Rating: 215 degrees Fahrenheit
• Minimum Temperature Rating: -22 degrees Fahrenheit
