Do It Best 442755 Submersible Splice Kit 14 to 8 Awg

Product Description

The DO IT BEST 442755 is a heat-shrinkable submersible splice kit designed to create watertight connections on submersible well pump motor leads. Each kit includes four Sta-Kon crimp connectors and four heat-shrinkable sleeves, giving a technician everything needed to complete one full splice job per kit. The heat-shrink sleeves seal the connection against moisture intrusion, which is critical in below-grade or submerged pump installations. Compatible wire gauges range from 14 AWG down to 8 AWG, covering the most common conductor sizes found in residential and light commercial well pump wiring.

This splice kit is used when extending, repairing, or replacing motor leads on submersible well pumps. It is appropriate for residential water well systems where pump motor leads must be joined in a wet environment below the water table. Water well contractors and licensed plumbers typically install this kit during pump pulls, motor replacements, or wiring repairs inside the well casing. The Sta-Kon connectors provide a mechanically secure crimp, and the heat-shrink sleeves provide the waterproof barrier required for reliable long-term service in submerged conditions.

Key Features

• Includes 4 Sta-Kon crimp connectors and 4 heat-shrinkable sleeves per kit
• Accepts wire gauges 14, 12, 10, and 8 AWG
• Heat-shrink sleeves create a watertight seal for submerged applications
• Designed specifically for submersible well pump motor lead splicing
• Compact kit format keeps all required components together for field use

Compatibility

Designed as an OEM-style replacement splice solution for submersible well pump motor leads using 14, 12, 10, or 8 AWG conductors in residential and light commercial well pump installations.

Installation Notes

Installation is typically performed by a licensed water well contractor or plumber during a pump pull or motor lead repair. De-energize the pump circuit at the breaker and verify the circuit is dead before making any connections. Use a calibrated crimping tool rated for the Sta-Kon connector series to ensure a proper mechanical crimp before applying heat to the shrink sleeve. Apply heat evenly along the full length of each sleeve using a heat gun until the sleeve contracts fully and adhesive seals around the conductor.

Technical Specifications

• Wire Gauge Range: 14, 12, 10, and 8 AWG
• Kit Contents: 4 Sta-Kon connectors, 4 heat-shrinkable sleeves
• Package Width: 2.06 inches
• Package Length: 1.25 inches
• Package Height: 3.69 inches
• Weight: 0.1 pounds
• Model Number: 024778
• UPC: 054757097660

Standard Information

• Brand: DO IT BEST
• Manufacturer Part Number: 442755
