Dixon Valve GL325 Dry Gauge - Pressure Measurement

Product Description

The Dixon Valve GL325 is a dry gauge designed for pumps, hydraulic and pneumatic systems, compressors, and machine tools. This gauge uses a C-shaped bronze bourdon tube and shows pressure readings on a dial. It is built to endure shock, vibration, and pulsation.

• Dial display type for clear readings
• 1/4 inch NPT(M) connection
• Maximum pressure capacity of 60 psi

Product Highlights

Reliable construction and suitable for various applications, the GL325 is an effective solution for pressure monitoring.

Product Information

Standard Information

• Brand: Dixon Valve
• MPN: GL325

Technical Specifications

• PSI: 0-60
• Maximum Operating Pressure: 60 psi
• Accuracy: ±3-2-3%
• Body Material: ABS
• Case Material: ABS
• Connection Size: 1/4 inch NPT(M)
• Dial Diameter: 2.5 inches
• Lens Material: Polycarbonate
• Operating Temperature (Max): 150 F
• Operating Temperature (Min): -40 F
• Weight: 0.2300 lbs
