DIXON VALVE G100-F-BR Cam and Groove Adapter

Product Description

The DIXON VALVE G100-F-BR is a cam and groove adapter for liquid connections. This adapter features a Type F connection on one end and a male NPT connection on the opposite end, both sizes measuring one inch. It is made from forged brass and meets the specifications for interchangeability with products following A-A-59326D.

• Type F and MNPT connections.
• Forged brass construction.
• Maximum operating pressure of 250 psi.

Product Highlights

This cam and groove adapter is designed for reliable performance in fluid transfer applications.

Product Information

Standard Information

• Fitting Type: Adapter
• Connection Size: 1 inch

Technical Specifications

• Connection Type 1: Type F
• Connection Type 2: MNPT
• Ends Configuration: 1 inch Male NPT, 1 inch Male Cam & Groove
• Cam Type: Type F
• Material: Brass
• Maximum Operating Pressure: 250 PSI
• Weight: 0.44 lb
• Dimensions: 1-7/16 inches Diameter x 2-25/32 inches Length
