Dixon Valve & Coupling SE3F3M Brass Fitting

Product Description

The Dixon Valve & Coupling SE3F3M is a brass fitting designed for pipe connections. It features a street elbow configuration allowing for a change in direction in a piping system. This fitting is compatible with both male and female pipe threads, making it versatile for various applications.

• Constructed from CA360 brass for durability.
• Working pressure rated up to 300 psi.
• Functions effectively in low-pressure lubrication lines and other fluids.

Product Highlights

This fitting is suitable for pneumatic, hydraulic, and general plumbing tasks.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: 101876587

Technical Specifications

• Working Pressure: 300 psi
• Material: CA360 Brass
• Application: Grease, Fuels, LP & Natural Gas (available on special order), refrigeration, instrumentation and hydraulic systems
• Female Pipe Size: 3/8 inches
• Temperature Range (Min): -60 °F
• Male Pipe Size: 3/8 inches
• Number of Ends: 2
• Fitting Angle: 90°
• Actual Fitting Type: Street Elbow
• End Types: NPT
• SAE Reference No.: 130239
• Temperature Range (Max): 200 °F
• Fitting Type: Elbow
• End Size: 3/8 NPT(f), 3/8 NPT(m)
• Weight: 0.18 LB
