Dixon Valve & Coupling GLSS160 Liquid Pressure Gauge 0-160 PSI

Product Description

The Dixon Valve & Coupling GLSS160 is a liquid pressure gauge designed for harsh conditions. It features a durable stainless steel case and a lower mounting style. This gauge is suitable for measuring pressures ranging from zero to one hundred sixty PSI.

• Pressure Gauge with stainless steel durability
• Temperature range from minus forty to one hundred fifty degrees Fahrenheit
• Lower mount with a two and a half-inch face diameter

Product Highlights

This gauge is ideal for severe service applications and offers excellent corrosion resistance.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: 101916369

Technical Specifications

• Gauge Type: Liquid
• Temperature Range [Max]: 150 °F
• Mounting Style: Lower Mount
• Temperature Range [Min]: -40 °F
• Gauge Pressure Range: 0 to 160 psi
• Case Material: Stainless Steel
• Gauge Function: Pressure Gauge
• NPT Male: 1/4 in
• Pressure Range [Max]: 160 PSI
• Pressure Range [Min]: 0 PSI
• Material: Stainless Steel
• Face Diameter: 2 1/2 in
• Weight: 0.51 LB
