Dixon Valve & Coupling GLS440 Liquid Pressure Gauge 0-1500 PSI

Product Description

The Dixon Valve & Coupling GLS440 is a liquid pressure gauge designed for reliable measurement in various applications. It features a durable stainless steel case and a strong PowerFlex movement to withstand shock and vibrations. This gauge is easy to mount and install, making it suitable for pumps, hydraulic systems, and machine tools.

• Gauge pressure range from 0 to 1,500 psi
• Lower mount with a face diameter of 2 1/2 inches
• Temperature range from -40°F to 150°F

Product Highlights

This gauge includes a non-corrosive movement ideal for rugged environments.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: GLS440

Technical Specifications

• Gauge Function: Pressure Gauge
• Mounting Style: Lower Mount
• Case Material: Stainless Steel
• NPT Male: 1/4 inches
• Face Diameter: 2 1/2 inches
• Pressure Range [Max]: 1500 PSI
• Pressure Range [Min]: 0 PSI
• Temperature Range [Max]: 150 °F
• Temperature Range [Min]: -40 °F
• Weight: 0.52 LB
• Gauge Type: Liquid
• Gauge Pressure Range: 0 to 1,500 psi
