Dixon Valve & Coupling GLS435 Liquid Pressure Gauge 0-1000 PSI

Product Description

The Dixon Valve & Coupling GLS435 is a reliable liquid pressure gauge with a maximum pressure of one thousand PSI. It features a lower mount design, a durable stainless steel case, and a convenient quarter-inch NPT connection.

• Pressure gauge range from zero to one thousand PSI
• Stainless steel construction for durability
• Lower mount for easy installation

Product Highlights

This gauge is designed for rugged service, making it suitable for pumps, hydraulic and pneumatic systems, and machine tools.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part #: 101895384

Technical Specifications

• Pressure Range [Max]: 1000 PSI
• Gauge Pressure Range: 0 to 1,000 psi
• NPT Male: 1/4 in
• Temperature Range [Max]: 150 °F
• Gauge Type: Liquid
• Temperature Range [Min]: -40 °F
• Gauge Function: Pressure Gauge
• Mounting Style: Lower Mount
• Face Diameter: 2 1/2 in
• Material: Stainless Steel
• Case Material: Stainless Steel
• Pressure Range [Min]: 0 PSI
• Weight: 0.52 LB
