Dixon Valve & Coupling GLS425 Liquid Pressure Gauge 0-300 PSI

Product Description

Dixon Valve & Coupling GLS425 is a liquid pressure gauge designed for pressure measurement. It offers a pressure range of zero to three hundred PSI. The gauge features a stainless steel case and a lower mount design, ideal for various industrial applications.

• PowerFlex movement for durability
• Suitable for pumps, hydraulic, and pneumatic systems
• Measured face diameter of two and a half inches

Product Highlights

This gauge is built to withstand rugged conditions, making it effective for machine tools and other demanding environments.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: GLS425

Technical Specifications

• Gauge Function: Pressure Gauge
• Face Diameter: 2.5 inches
• Gauge Pressure Range: 0 to 300 psi
• Temperature Range [Min]: -40 °F
• Case Material: Stainless Steel
• Mounting Style: Lower Mount
• Material: Stainless Steel
• NPT Male: 1/4 inches
• Pressure Range [Min]: 0 psi
• Pressure Range [Max]: 300 PSI
• Temperature Range [Max]: 150 °F
• Weight: 0.51 LB
