Dixon Valve & Coupling GLBR160 Liquid Pressure Gauge

Product Description

The Dixon Valve & Coupling GLBR160 is a liquid pressure gauge designed for reliable performance. It features a brass construction and measures pressure between zero and one hundred sixty PSI.

• Lower Mount
• 2 1/2 Inch Face Diameter
• 1/4 NPT Connection

Product Highlights

It is suitable for hydraulic and pneumatic systems, providing accurate pressure measurements in demanding environments.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: 101894786
• Minimum Order Quantity:
• Maximum Order Quantity:

Technical Specifications

• Gauge Function: Pressure Gauge
• Material: Brass
• NPT Male: 1/4 in
• Temperature Range [Max]: 140 °F
• Gauge Type: Liquid
• Pressure Range [Min]: 0 PSI
• Pressure Range [Max]: 160 PSI
• Face Diameter: 2 1/2 in
• Gauge Pressure Range: 0 to 160 psi
• Case Material: Brass
• Temperature Range [Min]: -40 °F
• Mounting Style: Lower Mount
• Weight: 0.81 LB
