Dixon Valve & Coupling GL340 Dry Pressure Gauge 0-200 PSI

Product Description

The Dixon Valve & Coupling GL340 is a dry pressure gauge designed for various applications. This gauge features a pressure range from zero to two hundred PSI, making it suitable for multiple systems. It has a lower mount style and a two and a half inch face diameter, which is optimal for easy reading.

• Lower Mount
• 2 1/2 Face Diameter
• ABS Plastic Case

Product Highlights

This gauge is built for reliable service under challenging conditions. It is commonly used in pumps, hydraulic systems, and compressors, ensuring a durable and non-corrosive movement.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: GL340

Technical Specifications

• Pressure Range [Max]: 200 PSI
• NPT Male: 1/4 in
• Case Material: ABS Plastic
• Gauge Type: Dry
• Gauge Pressure Range: 0 to 200 psi
• Mounting Style: Lower Mount
• Pressure Range [Min]: 0 PSI
• Temperature Range [Min]: -40 °F
• Material: ABS Plastic
• Gauge Function: Pressure Gauge
• Face Diameter: 2 1/2 in
• Temperature Range [Max]: 150 °F
• Weight: 0.23 LB
