Dixon Valve & Coupling GL135 Dry Pressure Gauge Power (2 inches) Replacement MPN

Product Description

The Dixon Valve & Coupling GL135 is a dry pressure gauge designed for accurate measurement in various applications. It features a two-inch face diameter and is suitable for both hydraulic and pneumatic systems. The gauge is made from ABS plastic, providing durability and resistance to corrosion.

• PowerFlex movement to endure shock, vibration, and pulsation.
• Temperature range from -40 to 150 degrees Fahrenheit.
• Standard 1/4 NPT fitting for easy connection.

Product Highlights

This gauge is ideal for use on pumps, compressors, and machine tools, ensuring reliable performance in demanding conditions.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: 101896048

Technical Specifications

• Face Diameter: 2 inches
• Case Material: ABS Plastic
• Temperature Range Minimum: -40 degrees Fahrenheit
• Gauge Pressure Range: 0 to 200 psi
• NPT Male: 1/4 inches
• Material: ABS Plastic
• Gauge Type: Dry
• Mounting Style: Lower Mount
• Pressure Range Minimum: 0 psi
• Temperature Range Maximum: 150 degrees Fahrenheit
• Gauge Function: Pressure Gauge
• Pressure Range Maximum: 200 psi
• Weight: 0.17 pounds
