Dixon Valve & Coupling GL115 Dry Pressure Gauge 0-30 PSI Replacement MPN

Product Description

The Dixon Valve & Coupling GL115 is a dry pressure gauge designed for reliable performance in demanding environments. This gauge features a lower mount design and is ideal for applications in various systems such as pumps, compressors, and machine tools.

• PowerFlex movement designed to resist shock and vibration
• ABS plastic case ensures durability
• Pressure range from 0 to 30 PSI

Product Highlights

Built for long service life, this gauge is suitable for hydraulic and pneumatic systems, providing accurate readings even in rugged conditions.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part #: 101893790

Technical Specifications

• Mounting Style: Lower Mount
• Pressure Range [Max]: 30 PSI
• Temperature Range [Max]: 150 °F
• Case Material: ABS Plastic
• Face Diameter: 2 inches
• Gauge Type: Dry
• Pressure Range [Min]: 0 PSI
• Gauge Pressure Range: 0 to 30 psi
• Temperature Range [Min]: -40 °F
• NPT Male: 1/4 inches
• Gauge Function: Pressure Gauge
• Material: ABS Plastic
• Weight: 0.17 LB
