Dixon Valve & Coupling GBR400 Dry Pressure Gauge 0 to 400 PSI

Product Description

The Dixon Valve & Coupling GBR400 is a dry pressure gauge suitable for measuring pressure in various applications. This gauge features a lower mount and is constructed with a brass case for durability. The face diameter measures two and a half inches, making it easy to read. Designed to measure pressures from zero to four hundred PSI, it operates effectively in a temperature range from negative ten to one hundred forty degrees Fahrenheit.

• Lower mount configuration
• Pressure range of 0 to 400 PSI
• Brass case for strength and durability

Product Highlights

The GBR400 pressure gauge is ideal for HVAC, plumbing, and industrial applications where reliable pressure readings are necessary.

Product Information

Standard Information

• Product Name: GBR400 | Dry Pressure Gauge
• Brand: Dixon Valve & Coupling

Technical Specifications

• Mounting Style: Lower Mount
• Case Material: Brass
• NPT Male: 1/4 in
• Pressure Range [Max]: 400 psi
• Temperature Range [Min]: -10 °F
• Temperature Range [Max]: 140 °F
• Pressure Range [Min]: 0 psi
• Gauge Function: Pressure Gauge
• Face Diameter: 2 1/2 in
• Gauge Pressure Range: 0 to 400 psi
• Gauge Type: Dry
• Weight: 0.316 LB
