Dixon G400-A-AL DIXON G400-A-AL 4 Inch Type A Cam and Groove Adapter - Aluminum

Product Description

The Dixon G400-A-AL is a 4-inch Type A cam and groove adapter made of A380 molded aluminum. It features Buna seals and is designed to fit products that meet A-A-59326D specifications. This fitting has a male adapter and FNPT connection style. It measures three and one-sixteenth inches in length and is suitable for use with liquids. The maximum pressure rating is one hundred psi at seventy degrees Fahrenheit when paired with compatible Dixon fittings and a standard seal. The hex size for this adapter is four and twenty-seven thirty-seconds inches.

• A380 molded aluminum construction
• Type A male adapter with FNPT connection
• Pressure rated to one hundred psi at seventy degrees Fahrenheit

Product Highlights

This adapter is essential for various plumbing applications where liquid transfer is required. It should not be used with compressed air or steam, nor connected to drinking water systems.

Product Information

Standard Information

• Brand: Dixon
• Part Number: G400-A-AL

Technical Specifications

• Connection Size 1: 4 in
• Connection Size 2: 4 in
• Connection Type: Type A FNPT
• Dimensions: 3-1/16 in L
• Hex Size: 4-27/32 in
• Material: Aluminum
• Maximum Operating Pressure: 100 psi
• Weight: 1.15 lb
