Dixon BV2CV-150CC-A 3-Piece 2-Way Encapsulated Ball Valve 1-1/2 in Clamp

Product Description

The Dixon BV2CV-150CC-A is a sanitary ball valve designed for reliable performance. This 3-piece, 2-way encapsulated valve features a one and a half inch clamp connection and is made from stainless steel for durability. It operates at a maximum pressure rating of one thousand psi WOG and can handle temperatures up to three hundred degrees Fahrenheit. The full port design ensures optimal flow.

• 3-piece body allows for easy maintenance
• Live-loaded stem packing enhances reliability
• ISO 5211 mounting pad for easy actuator installation

Product Highlights

The design of this valve enables a bubble tight seal, making it suitable for various applications in sanitary systems.

Product Information

Standard Information

• Brand: Dixon
• Manufacturer: Dixon Valve & Coupling

Technical Specifications

• Body Material: Stainless Steel
• Dimensions: 5.6 in L
• End Style: Clamp
• Nominal Size: 1-1/2 in
• Port Type: Full
• Pressure Rating: 1000 psi WOG
• Series: BV2C
• Temperature Rating: 300 deg F
• Trim Material: PTFE
• Type: 3-Piece 2-Way Encapsulated
