Dixon BV2CV-100CC-A Ball Valve 1 in Clamp Replacement MPN

Product Description

The Dixon Sanitary BV2CV-100CC-A is a three-piece, two-way encapsulated ball valve made of stainless steel. This valve features a clamp connection and is designed for a nominal size of one inch. The valve provides a pressure rating of one thousand psi WOG and can withstand temperatures up to three hundred degrees Fahrenheit. It is designed for optimal performance in sanitary applications.

• Full port design for improved flow.
• Stainless steel body ensures durability.
• Easy maintenance with a three-piece body design.

Product Highlights

This ball valve includes live-loaded stem packing and an ISO 5211 mounting pad. It also features a blow-out proof stem design that contributes to safety and reliability.

Product Information

Standard Information

• Brand: Dixon
• Manufacturer: Dixon Valve & Coupling

Technical Specifications

• Ball Material: Stainless Steel
• Body Material: Stainless Steel
• End Style: Clamp
• Inlet to Outlet Length: 4.9 inches
• Nominal Size: 1 inch
• Port Type: Full
• Pressure Rating: 1000 psi WOG
• Series: BV2C
• Temperature Rating: 300 degrees Fahrenheit
• Top to Inlet Center: 2.1 inches
• Trim Material: PTFE
• Type: 3-Piece 2-Way Encapsulated
