Dixon B38SL-G300 Slip-On Flange 3 in 150 lb

Product Description

The Dixon B38SL-G300 is a slip-on flange made from 304/304L stainless steel. It has a nominal size of three inches with an inside diameter measuring 3.063 inches. This flange features a thickness of one-half inch and integrates four bolt holes, each sized at three-quarters of an inch. The bolt circle diameter is six inches, and the overall outside diameter reaches seven and a half inches. Rated for a pressure class of 150 lb, this domestic, unpolished flange is designed for durability and reliability in various applications.

• Nominal Size: 3 inches
• Material: 304/304L Stainless Steel
• Pressure Class: 150 lb

Product Highlights

The Dixon B38SL-G300 flange is essential for secure connections in piping systems, suitable for HVAC and plumbing needs.

Product Information

Standard Information

• Brand: Dixon
• Manufacturer: Dixon Valve & Coupling

Technical Specifications

• Inside Diameter: 3.063 inches
• Thickness: 1/2 inches
• Outside Diameter: 7-1/2 inches
• Bolt Circle Diameter: 6 inches
• Number of Bolt Holes: 4
• Bolt Hole Size: 3/4 inches
• Domestic/Import: Domestic
• Finish: Unpolished
