Diversitech QTM2 Line Tap Valve 1/2in., 5/8in. O.D. Tube Size

Product Description

The DiversiTech QTM2 MAC line piercing valve features one connection for piercing and servicing. Designed for 1/2 and 5/8 in. OD tubing. The needle automatically back-seats after servicing, leaving the line free of restriction. Connects to tubing with two socket-head screws. When the hose is removed, the spring-loaded needle back-seats, forming a leak-proof seal.

• Sealed with refrigerant resistant O-rings
• Provides leak proof seal
• Easy to use and install

Product Highlights

The DiversiTech QTM2 line tap valve is easy to install and provides a secure, leak-proof seal for HVAC systems.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: QTM2

Technical Specifications

• MPN: QTM2
• Brand: DIVERSITECH
• Ducted or Ductless: Both Ducted and Ductless
• Tube Size: 1/2 in._5/8 in.
• Body Material: Metal
• Nominal Size: 1/2, 5/8 in OD
• Temperature Rating: 300 deg F Resist
• Prop65: No
• Domestic/Import: Import
• Includes: Hex Wrench
