Diversitech el5060-3 Plastic Equipment Pad 50x60x3 in

Product Description

The DIVERSITECH el5060-3 is a rectangular polypropylene equipment pad designed as a stable mounting base for residential and light commercial condenser and heat pump units. Measuring 50 inches long by 60 inches wide by 3 inches tall, this gray pad is injection molded from 98% recycled, UV-inhibited polypropylene for lasting outdoor performance. Internal ribbing distributes load across the pad surface and supports a rated capacity of 2,080 pounds. The lightweight construction makes single-technician handling practical on the job site without sacrificing structural integrity.

This pad is suited for ducted condenser and heat pump installations where a level, stable equipment base is required. Its self-leveling ground support design accommodates minor surface irregularities, reducing the need for shimming on typical residential or light commercial grade-level installations. The drillable surface allows field fabrication of anchor or drainage points as required by local mechanical codes or equipment manufacturer instructions. HVAC technicians and installation crews are the primary installers for this product.

Key Features

• 50 x 60 x 3 inch rectangular form factor sized for large condenser and heat pump footprints
• 2,080-pound load capacity handles typical residential and light commercial condensing units
• Injection-molded polypropylene construction with internal ribbing for structural strength
• Made from 98% recycled, UV-inhibited material for weather resistance and long outdoor service life
• Drillable surface allows field modification for anchoring or drainage requirements
• Lightweight design simplifies handling and placement during installation

Compatibility

Designed as a grade-level mounting pad for ducted condensers and heat pump outdoor units requiring a rectangular base footprint of approximately 50 x 60 inches.

Installation Notes

Installation is typically performed by a licensed HVAC technician. Prepare a flat, compacted surface before placing the pad to ensure proper equipment alignment and drainage away from the unit. Verify that local mechanical codes and equipment manufacturer instructions are followed for anchoring requirements before drilling the pad. Power down and lock out the electrical disconnect to the outdoor unit before performing any work in the immediate area.

Technical Specifications

• Material: Polypropylene (98% recycled)
• Color: Gray
• Length: 50 inches
• Width: 60 inches
• Height: 3 inches
• Load Capacity: 2,080 pounds
• Shape: Rectangular
• UV Resistant: Yes
• Drillable: Yes
• Application: Condensers, Heat Pump
• Ducted or Ductless: Ducted

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: el5060-3
